| Prosessorprodusent | Intel |
| Prosessorstøpsel | LGA 3647 (Socket P) |
| Antall prosessorkjerner som støttes | 4, 6, 8, 10, 12, 14, 16, 18, 20, 22 |
| Antall QPI-koblinger | 2 |
| Maksimalt antall PCI Express-spor | 80 |
| Maksimalt internminne støttet av prosessor | 1,28 TB |
| Minnebåndbredde støttet av prosessor (maks.) | 255,94 GB/s |
| EEC støttet av prosessor | Ja |
| Produktfamilie | Intel compute module |
| Produktserie | Intel® Compute Module HNS2600BP Family |
| Produktkodenavn | Buchanan Pass |
| Støttede minnetyper | DDR4-SDRAM |
| ECC | Ja |
| Støttede minneklokkehastigheter | 2133,2400,2666 MHz |
| Maksimalt internminne | 1,28 TB |
| Støttede lagringsgrensesnitt | SATA |
| RAID-nivåer | 0, 1, 5, 10, 50 |
| On-board grafikkort | Nei |
| Antall SATA-tilkoblinger | 4 |
| Totalt antall SATA-kontakter | 4 |
| Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter | 2 |
| Antall ethernets-/bredbåndstilkoblinger (RJ-45) | 2 |
| Antall VGA (D-Sub)-porter | 1 |
| Kommunikasjonsserieporter | 1 |
| Ethernet/bredbåndsforbindelse | Ja |
| Ethernet-grensesnittype | Gigabit Ethernet |
| Wi-Fi | Nei |
| Komponent for | Server |
| Systemkort kretsoppsett | Intel C622 |
| Physical Address Extension (PAE) | 50 bit |
| Hyllevennlig brett | Ja |
| Embedded USB (eUSB) SSD-alternativ | Nei |
| Kompatible operativsystemer | Windows Server 2016*, Windows Server 2012 R2*, Red Hat Enterprise Linux 7.3*, SUSE Linux Enterprise Server 12 SP2*, CentOS 7.3* |
| PCI Express x16 (Gen 3.x) slots | 2 |
| PCI Express sporversjon | 3.0 |
| BIOS-type | UEFI |
| Intel® Fast Memory Access | Ja |
| Trusted Platform Module (TPM) | Ja |
| Intel® Trusted Execution Technology | Ja |
| Intel® Rapid Storage Technology | Nei |
| Intel® I/O Acceleration Technology | Ja |
| Intel® Flex Memory Access | Ja |
| Intel® AES New Instructions (Intel® AES-NI) | Ja |
| Trusted Platform Module (TPM)-versjon | 2.0 |
| Intel Virtualisering Technology for Directed I/O (VT-d) | Ja |
| Intel Rapid Lager Teknologi enterprise | Ja |
| Intelligent Platform Management Interface (IPMI) support | Ja |
| Intel® Advanced Management Technology | Ja |
| Intel® Server Management Software | Ja |
| Intel® Remote Management Module Support | Ja |
| Intel® Server Customization Technology | Ja |
| Intel® Build Assurance Technology | Ja |
| Intel® Quiet Thermal Technology | Ja |
| Intel® Efficient Power Technology | Ja |
| Intel® Intel®ligent Power Node Manager | Ja |
| Integrert BMC med IPMI | Ja |
| Integrerte systemer tilgjengelige | Ja |
| Intel® Optane™ Memory Ready | Ja |
| Intel® Optane™ DC Persistent Memory-teknologi | Ja |
| Harmonisert system (HS)-kode | 8473301180 |
| Bredde | 172,7 mm |
| Dybde | 485,1 mm |
| Støttet LRDIMM klokkehastigheter | 2133,2400,2666 MHz |
| Støttede RDIMM-klokkehastigheter | 2133,2400,2666 MHz |
| Antall DIMM-porter | 16 |
| Antall prosessorer som støttes | 2 |
| Integrerte alternativer tilgjengelige | Nei |
| Prosessorkonfigurasjon (maks.) | 2 |
| PCI Express CEM-revisjon | 3.0 |
| Pakkeinnhold | (1) 1U node tray(1) Intel Server Board S2600BPS(1) Power Docking Board FHWBPNPB24, (3) 40x56mm dual rotor managed fans FXX4056DRFAN2(1) 1U passive Rear heat sink – CPU #1 – CuAL – FXXHP78X108HS(1) 1U passive heat sink – CPU #2 – AL – FXXEA78X108HS(1) Air duct(1) External VGA port bracket (1) Slot 2 riser card w/80mm M.2 SSD slot. Required Items – Sold Separately: One (1) bridge board option - AHWBPBGB24, AHWBPBGB24R OR AHWBPBGB24P; One or two Intel Xeon Scalable family,Up to Sixteen (16) DDR4 RDIMM/LRDIMM |
| Chassis-type | 2U Rack |
| Thermal Design Power (TDP) | 165 W |
| Hovedkortets ARK-ID | 96350 |
| Grafikkutgang | VGA |
| Intel Node Manager | Ja |
| Produkttype | Server/Workstation Board |
| Antall USB-porter | 2 |
| Formfaktor | Custom 6.8" x 19.1" |
| Lanseringsdato | Q3'17 |
| Status | Launched |
| Støttet RAID-konfigurasjon | RAID Levels 0/1/10/5/50 (LSI) |
| Forventet utløpsdato | Q3'19 |
| Siste ordredato | Thursday, August 22, 2019 |
| Utløpsdato | Monday, April 22, 2019 |
| URL for mer informasjon | http://www.intel.com/content/www/us/en/data-center-blocks/hpc/hpc-compute-blocks.html?cache=no |
| Antall spor i stigekort nr. 1 | 16 |
| Antall spor i stigekort nr. 2 | 24 |
| Antall spor i stigekort nr. 3 | 24 |
| Hever spor 4 antall filer | 16 |
