Systemkort kretsoppsett Intel® C612 |
Prosessorstøpsel LGA 2011-v3 |
Prosessorfamilie Intel |
Antall prosessorer som støttes 2 |
Maksimalt internminne støttet av prosessor 1,54 TB |
Kompatible prosessorserier Intel® Xeon® |
Intel® Xeon series E5-2600 |
|
Antall DIMM-porter 24 |
Støttede minnetyper DDR4-SDRAM |
Maksimalt internminne 1,54 TB |
Maksimalt RDIMM-minne 1,54 TB |
Støttede RDIMM-klokkehastigheter 1600,1866,2133 MHz |
ECC |
|
Antall lagringsdrivere som støttes 8 |
Harddisk hot swap |
Antall 2.5" bays 8 |
Støttede lagringsdriverstørrelser 2.5" |
RAID-nivåer 0, 1, 10 |
Embedded USB (eUSB) SSD-alternativ |
|
Ethernet/bredbåndsforbindelse |
Ethernet-grensesnittype 10 Gigabit Ethernet |
Ethernet LAN dataoverføringshastigheter 10000 Mbit/s |
|
Antall USB-porter 5 |
Antall USB 2.0-porter 5 |
Antall ethernets-/bredbåndstilkoblinger (RJ-45) 2 |
Kommunikasjonsserieporter 2 |
InfiniBand |
Antall SATA-tilkoblinger 10 |
|
PCI Express x4 (Gen 2.x) slots 1 |
PCI Express x8 (Gen 3.x) slots 3 |
PCI Express x16 (Gen 3.x) slots 2 |
|
Integrert BMC med IPMI |
Trusted Platform Module (TPM) |
Trusted Platform Module (TPM)-versjon 1.2 |
Bakplan-støtte |
Merket segment Server |
ARK ID 88282 |
Intel Node Manager |
Bakplaner Included |
|
Harmonisert system (HS)-kode 8473305100 |
|
Intel® Virtualization Technology (Intel® VT) VT-d |
Intel® Rapid Storage Technology |
Intel® Advanced Management Technology |
Intel® I/O Acceleration Technology |
Intel Rapid Lager Teknologi enterprise |
Intel® Build Assurance Technology |
Intel® Quiet Thermal Technology |
Intel® Remote Management Module Support |
Intel® Quiet System Technology (QST) |
Intel® Efficient Power Technology |
Intel® On-Demand Power Redundancy Technology |
Intel® Fast Memory Access |
Intel® Intel®ligent Power Node Manager |
Intel® Flex Memory Access |
Intel® Server Customization Technology |
Intel® Matrix Storage Technology (Intel® MST) |
Intel Virtualisering Technology for Directed I/O (VT-d) |
Intel® Server Management Software |
Kontakt for Intel I / O utvidelsesmodul x8 Gen 3 1 |
Intern I / O utvidelsesmodul x8 Gen 3 1 |
|
Chassis-type Rack (2U) |
Produktfarge Rustfritt stål |
Rack skinner |
Hyllevennlig brett |
Redundante fans støtter |
Kjøleplate inkludert |
Kjøleplate 2 |
Antall vifter 2 vifter |
|
Type strømforsyning AC |
Krav til strømforsyning 1100 W |
Redundant strømforsyning |
Antall strømforsyninger 2 |
|
Pakkeinnhold (1) Intel Server Board S2600WTTR w/ Dual 10GbE; (1) front I/O panel assembly (front 1xVGA and 2x USB); (1) airduct for passive Intel Xeon Phi Co cards (AWTCOPRODUCT); (2) 12V-Auxiliary Power Cables; (1) standard control panel board (FXXFPANEL); (1) SATA Optical drive bay with filler panel (Include: optical drive mounting latch kit and 300mm optical drive / internal mount SSD power cable); (8) 2.5 inch hot-swap drive carriers (FXX8X25S3HSBP); (1) 12Gb SAS backplane (FXX8X25S3HSBP); (1) Backplane power cable; (1) Backplane 250mm I2C cable; (2) Multiport 730mm SAS/SATA data cables; (2) processor heatsinks (FXXCA84X106HS); (6) redundant and hot-swap cooling fans (FR2UFAN60HSW); (2) risers with 1x16 and 1x8 PCIe* 3.0 slots each (A2UL16RISER2); (1) riser with 1x8 PCIe* 3.0 and 1x4 PCIe* 2.0 slot (A2UX8X4RISER); (2) power cables (A2UL16RISER2); (1) battery backup unit bracket with three mounting locations over the airduct; (2) 1100W AC power supply (FXX1100PCRPS) |
|
Prosessorkonfigurasjon (maks.) 2 |
On-board grafikkort |
Produkttype System |
2,5" harddisk støtte Hot-swap 2.5" |
URL for mer informasjon |
Chassisdimensjoner 430 x 709,9 x 87,4 mm (16.9 x 27.9 x 3.44") |
Forventet utløpsdato Q3'20 |
Utvidet garanti tilgjengelig for kjøp (velg land) |
Siste endring 63903513 |
Lanseringsdato Q1'16 |
Optisk stasjon støttes |
Overflødige/ekstra vifter |
Status Launched |
Støttet RAID-konfigurasjon SW RAID 0, 1, 10, optional 5 |
Støttet bord Intel Server Board S2600WTTR |
Målgruppe Cloud/Datacenter |
Bildekart |
Produktfamilie 2U server system |
Produktserie Intel R2000WT |
Produktkodenavn Wildcat Pass |
